CPLDs (Complex Programmable Logic Devices)
CPLDs are user-configurable integrated circuit products used for performing logical operations and information processing, which incorporate a higher level of functionality (i.e. more logic gates) than is characteristic of PLD or PAL devices, though less than that of FPGAs. Characteristically, CPLDs incorporate non-volatile configuration memory that enables storage and retention of the user's desired configuration directly on the device, with retention of this information when power to the device is removed.
Browse CPLDs (Complex Programmable Logic Devices) by MPN. We highlight stock availability, support BOM matching, and source through original / verified channels.
Product List
Total Components: 5,034
| Product | Pricing | Datasheet | Delay Time tpd(1) Max | Voltage Supply - Internal | Number of Logic Elements/Blocks | Number of Gates | Number of I/O | Number of Macrocells | Programmable Type | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Stock & Quantity |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LC4064ZE-7MN144I Lattice Semiconductor | 1 $6.1750 | 7.5 ns | 1.7V ~ 1.9V | 4 | - | 64 | 64 | In System Programmable | Surface Mount | -40°C ~ 105°C (TJ) | 144-TFBGA, CSPBGA | 144-CSBGA (7x7) | 9,589 | |
 LC4064ZC-5TN48C Lattice Semiconductor | 1 $6.2400 | 5 ns | 1.7V ~ 1.9V | 4 | - | 32 | 64 | In System Programmable | Surface Mount | 0°C ~ 90°C (TJ) | 48-LQFP | 48-TQFP (7x7) | 4,447 | |
 LC4256ZC-75TN176E Lattice Semiconductor | 1 $38.4000 | 7.5 ns | 1.7V ~ 1.9V | 16 | - | 128 | 256 | In System Programmable | Surface Mount | -40°C ~ 130°C (TJ) | 176-LQFP | 176-TQFP (24x24) | 2,837 | |
 ATF750C-7PX Atmel (Microchip Technology) | 1 $1.0000 | 7.5 ns | 4.75V ~ 5.25V | - | - | 10 | 10 | EE PLD | Through Hole | 0°C ~ 70°C (TA) | 24-DIP (0.300", 7.62mm) | 24-PDIP | 4,150 | |
 ATF1508ASL-25QC100 Microchip Technology | 25 ns | 4.75V ~ 5.25V | - | - | 80 | 128 | In System Programmable (min 10K program/erase cycles) | Surface Mount | 0°C ~ 70°C (TA) | 100-BQFP | 100-PQFP (14x20) | 6,999 | ||
 XC9536XV-5PC44C AMD Xilinx | 1 $22.6460 | 5 ns | 2.37V ~ 2.62V | 2 | 800 | 34 | 36 | In System Programmable | Surface Mount | 0°C ~ 70°C (TA) | 44-LCC (J-Lead) | 44-PLCC (16.59x16.59) | 100,000 | |
 EPM240GT100I5N Altera (Intel) | 4.7 ns | 1.71V ~ 1.89V | 240 | - | 80 | 192 | In System Programmable | Surface Mount | -40°C ~ 100°C (TJ) | 100-TQFP | 100-TQFP (14x14) | 8,555 | ||
 LC5512MB-75FN256C Lattice Semiconductor | 7.5 ns | 2.3V ~ 2.7V | 16 | - | 193 | 512 | In System Programmable | Surface Mount | 0°C ~ 90°C (TJ) | 256-BGA | 256-FPBGA (17x17) | 2,524 | ||
 ISPLSI 5384VA-100LB272 Lattice Semiconductor | 10 ns | 3V ~ 3.6V | 12 | 18000 | 192 | 384 | In System Programmable | Surface Mount | 0°C ~ 70°C (TA) | 272-BBGA | 272-BGA (27x27) | 9,593 | ||
LC4256C-5FN256AC Lattice Semiconductor | 1 $28.8600 | - | - | - | - | - | - | - | - | - | - | - | 1,510 | |
LC4512C-35T176C Lattice Semiconductor | 3.5 ns | 1.65V ~ 1.95V | 32 | - | 128 | 512 | In System Programmable | Surface Mount | 0°C ~ 90°C (TJ) | 176-LQFP | 176-TQFP (24x24) | 2,844 | ||
 M5-256/160-10YI/1 Lattice Semiconductor | 10 ns | 4.5V ~ 5.5V | - | - | 160 | 256 | In System Programmable | Surface Mount | -40°C ~ 85°C (TA) | 208-BFQFP | 208-PQFP (28x28) | 3,557 | ||
GAL20V8B-15LPN Lattice Semiconductor | 15 ns | 4.75V ~ 5.25V | - | - | - | 8 | EE PLD | Through Hole | 0°C ~ 75°C (TA) | 24-DIP (0.300", 7.62mm) | 24-PDIP | 1,998 | ||
 ISPLSI 2096A-100LT128 Lattice Semiconductor | 10 ns | 4.75V ~ 5.25V | 24 | 4000 | 96 | 96 | In System Programmable | Surface Mount | 0°C ~ 70°C (TA) | 128-LQFP | 128-TQFP (14x14) | 3,118 | ||
XCR3512XL-12PQ208I AMD Xilinx | 10.8 ns | 2.7V ~ 3.6V | 32 | 12000 | 180 | 512 | In System Programmable (min 1K program/erase cycles) | Surface Mount | -40°C ~ 85°C (TA) | 208-BFQFP | 208-PQFP (28x28) | 9,272 | ||
 EPM7128AELC84-5 Altera (Intel) | 5 ns | 3V ~ 3.6V | 8 | 2500 | 68 | 128 | In System Programmable | Surface Mount | 0°C ~ 70°C (TA) | 84-LCC (J-Lead) | 84-PLCC (29.31x29.31) | 2,038 | ||
EPM9560ARI208-10 Altera (Intel) | 1 $128.5714 100 $102.8571 500 $85.7143 | 10 ns | 4.5V ~ 5.5V | 35 | 12000 | 153 | 560 | In System Programmable | Surface Mount | -40°C ~ 85°C (TA) | 208-BFQFP Exposed Pad | 208-RQFP (28x28) | 10 | |
EPM7512AEFC256-10 Altera (Intel) | 10 ns | 3V ~ 3.6V | 32 | 10000 | 212 | 512 | In System Programmable | Surface Mount | 0°C ~ 70°C (TA) | 256-BGA | 256-FBGA (17x17) | 1,362 | ||
 EPM7512AEBC256-6EM Altera (Intel) | 6 ns | 3V ~ 3.6V | 32 | 10000 | 212 | 512 | In System Programmable | Surface Mount | 0°C ~ 70°C (TA) | 256-LBGA | 256-BGA (27x27) | 5,347 | ||
 XC95144XL-5TQG144C AMD Xilinx | 1 $57.4700 | 5 ns | 3V ~ 3.6V | 8 | 3200 | 117 | 144 | In System Programmable (min 10K program/erase cycles) | Surface Mount | 0°C ~ 70°C (TA) | 144-LQFP | 144-TQFP (20x20) | 4,882 |
