LED Lighting - Color

Color LEDs used for illumination are characterized by fixed wavelength, wavelength range, and color group as well as 60 to 170 degree viewing angles. LEDS are available in surface mount packages such as SMD, CSDM, PLCC, J-lead, gull wing, exposed pad, and a wide variety of metric sizes as well as through-hole TO-252, DPak, SC-63, and radial lead configurations.

Sourcing Avago Technologies (Broadcom) LED Lighting - Color: in-stock lines for quick ship, BOM matching for multi-line builds, and original-channel screening — not keyword stuffing.

BOM matching · Lead time · Authenticity · Brands

Product	Pricing	Datasheet	Color	Mounting Type	Size / Dimension	Current - Max	Current - Test	Lumens/Watt @ Current - Test	Luminous Flux @ Current/Temperature	Temperature - Test	Height - Seated (Max)	Package / Case	Supplier Device Package	Viewing Angle	Voltage - Forward (Vf) (Typ)	Wavelength	Stock & Quantity
ASMT-JR10-ARS01 Avago Technologies (Broadcom)	1 $1.9817	Datasheet	Red	Surface Mount	0.157" L x 0.157" W (4.00mm x 4.00mm)	500mA	350mA	95 lm/W	70lm (52lm ~ 87lm)	25°C	0.077" (1.95mm)	6-SMD, Flat Lead Exposed Pad	-	165°	2.1V	628nm (620nm ~ 635nm)	4,723 Buy Now Get Quote
ASMT-AB00-NMP00 Avago Technologies (Broadcom)	1 $2.0237	Datasheet	Blue	Surface Mount	0.315" Dia (8.00mm)	500mA	350mA	20 lm/W	22lm (14lm ~ 31lm)	25°C	0.165" (4.20mm)	2-SMD, Gull Wing Exposed Pad	2-SMD	140°	3.2V	465nm (455nm ~ 475nm)	3,334 Buy Now Get Quote
ASMT-JB31-NMP01 Avago Technologies (Broadcom)	1 $2.0237	Datasheet	Blue	Surface Mount	0.157" L x 0.157" W (4.00mm x 4.00mm)	700mA	350mA	21 lm/W	24lm (18lm ~ 31lm)	25°C	0.077" (1.95mm)	6-SMD, Flat Lead Exposed Pad	-	165°	3.2V	465nm (455nm ~ 475nm)	8,554 Buy Now Get Quote
ASMT-JL31-NRS01 Avago Technologies (Broadcom)	1 $2.0237	Datasheet	Blue	Surface Mount	0.157" L x 0.157" W (4.00mm x 4.00mm)	700mA	350mA	-	600mW (515mW ~ 685mW)	25°C	0.077" (1.95mm)	6-SMD, Flat Lead Exposed Pad	-	165°	3.2V	450nm (440nm ~ 460nm)	4,769 Buy Now Get Quote
ASMT-AG31-NUV00 Avago Technologies (Broadcom)	1 $2.8550	Datasheet	Green	Surface Mount	0.315" Dia (8.00mm)	700mA	350mA	94 lm/W	105lm (Typ)	25°C	0.165" (4.20mm)	2-SMD, Gull Wing Exposed Pad	2-SMD	140°	3.6V	525nm (Typ)	5,617 Buy Now Get Quote
ASMT-AL31-NRS00 Avago Technologies (Broadcom)	1 $3.1111	Datasheet	Blue	Surface Mount	0.315" Dia (8.00mm)	700mA	350mA	-	600mW (515mW ~ 685mW)	25°C	0.165" (4.20mm)	2-SMD, Gull Wing Exposed Pad	2-SMD	140°	3.2V	450nm (440nm ~ 460nm)	2,446 Buy Now Get Quote
ASMT-QAB2-FDE0E Avago Technologies (Broadcom)		Datasheet	Amber	Surface Mount	0.126" L x 0.110" W (3.20mm x 2.80mm)	150mA	150mA	30 lm/W	12lm (9lm ~ 15lm)	25°C	0.083" (2.10mm)	4-PLCC	4-PLCC	120°	2.7V	591nm (583nm ~ 598nm)	6,610 Buy Now Get Quote
ASMT-QHB2-FEF0E Avago Technologies (Broadcom)		Datasheet	Red	Surface Mount	0.126" L x 0.110" W (3.20mm x 2.80mm)	150mA	150mA	40 lm/W	16lm (12lm ~ 20lm)	25°C	0.083" (2.10mm)	4-PLCC	4-PLCC	120°	2.7V	618nm (611nm ~ 625nm)	9,401 Buy Now Get Quote
ASMT-JD30-ALN01 Avago Technologies (Broadcom)		Datasheet	Red	Surface Mount	0.157" L x 0.157" W (4.00mm x 4.00mm)	700mA	350mA	-	-	25°C	0.077" (1.95mm)	6-SMD, Flat Lead Exposed Pad	-	165°	2.1V	640nm (620nm ~ 635nm)	2,678 Buy Now Get Quote
ASMT-QBBC-NAC0E Avago Technologies (Broadcom)		Datasheet	Blue	Surface Mount	0.126" L x 0.110" W (3.20mm x 2.80mm)	300mA	150mA	14 lm/W	7lm (4lm ~ 9lm)	25°C	0.083" (2.10mm)	4-PLCC	4-PLCC	120°	3.4V	470nm (460nm ~ 480nm)	1,857 Buy Now Get Quote
ASM6-SL92-NTV0H Avago Technologies (Broadcom)	1 $3.5200	Datasheet	Royal Blue	Surface Mount	0.136" L x 0.136" W (3.45mm x 3.45mm)	1A	350mA	-	730mW (610mW ~ 930mW)	25°C	0.106" (2.70mm)	3-SMD, No Lead	3-SMD	90°	2.9V	450nm (440nm ~ 460nm)	3,727 Buy Now Get Quote
ASM6-S390-ANQ0H Avago Technologies (Broadcom)	1 $3.8700	Datasheet	Red	Surface Mount	0.136" L x 0.136" W (3.45mm x 3.45mm)	700mA	350mA	-	350mW (330mW ~ 480mW)	25°C	0.106" (2.70mm)	3-SMD, No Lead	3-SMD	90°	2.1V	735nm (720nm ~ 745nm)	4,178 Buy Now Get Quote
ASM6-S3D0-ANQ0H Avago Technologies (Broadcom)	1 $3.9400	Datasheet	Red	Surface Mount	0.136" L x 0.136" W (3.45mm x 3.45mm)	700mA	350mA	-	350mW (330mW ~ 480mW)	25°C	0.083" (2.10mm)	3-SMD, No Lead	3-SMD	130°	2.1V	735nm (720nm ~ 745nm)	4,422 Buy Now Get Quote
ASMT-JA30-ARS01 Avago Technologies (Broadcom)	1 $4.6200	Datasheet	Amber	Surface Mount	0.157" L x 0.157" W (4.00mm x 4.00mm)	700mA	350mA	73 lm/W	54lm (40lm ~ 62lm)	25°C	0.077" (1.95mm)	6-SMD, Flat Lead Exposed Pad	-	165°	2.1V	592nm (587nm ~ 597nm)	8,577 Buy Now Get Quote
ASMT-QHBD-AFH0E Avago Technologies (Broadcom)	1 $1.4100	Datasheet	Red	Surface Mount	0.126" L x 0.110" W (3.20mm x 2.80mm)	300mA	150mA	64 lm/W	24lm (15lm ~ 33lm)	25°C	0.083" (2.10mm)	4-PLCC	4-PLCC	120°	2.5V	618nm (611nm ~ 625nm)	4,397 Buy Now Get Quote
ASMT-QABD-AEF0E Avago Technologies (Broadcom)	1 $1.4100	Datasheet	Amber	Surface Mount	0.126" L x 0.110" W (3.20mm x 2.80mm)	300mA	150mA	46 lm/W	16lm (12lm ~ 20lm)	25°C	0.083" (2.10mm)	4-PLCC	4-PLCC	120°	2.3V	591nm (583nm ~ 598nm)	1,763 Buy Now Get Quote
ASMT-AA00-ARS01 Avago Technologies (Broadcom)		Datasheet	Amber	Surface Mount	0.315" Dia (8.00mm)	500mA	350mA	68 lm/W	50lm (Typ)	25°C	0.165" (4.20mm)	2-SMD, Gull Wing Exposed Pad	2-SMD	140°	2.1V	590nm (Typ)	6,121 Buy Now Get Quote
ASMT-AA00-ARSN0 Avago Technologies (Broadcom)		Datasheet	Amber	Surface Mount	0.315" Dia (8.00mm)	500mA	350mA	68 lm/W	50lm (Typ)	25°C	0.165" (4.20mm)	2-SMD, Gull Wing Exposed Pad	2-SMD	140°	2.1V	590nm (Typ)	7,581 Buy Now Get Quote
ASM3-SDD0-ANP0H Avago Technologies (Broadcom)	1 $3.0100	Datasheet	Red	Surface Mount	0.136" L x 0.136" W (3.45mm x 3.45mm)	700mA	350mA	-	350mW (330mW ~ 430mW)	25°C	0.085" (2.15mm)	1414 (3535 Metric)	3535	130°	2.1V	655nm (650nm ~ 670nm)	1,764 Buy Now Get Quote
ASMW-L300-AFH0E Avago Technologies (Broadcom)	1 $0.5008	Datasheet	Red	Surface Mount	0.138" L x 0.110" W (3.50mm x 2.80mm)	200mA	150mA	-	95mW (65mW ~ 140mW)	25°C	0.035" (0.90mm)	1113 (2835 Metric)	2835	120°	2.16V	731nm (720nm ~ 745nm)	3,791 Buy Now Get Quote
