LED Lighting - Color
Color LEDs used for illumination are characterized by fixed wavelength, wavelength range, and color group as well as 60 to 170 degree viewing angles. LEDS are available in surface mount packages such as SMD, CSDM, PLCC, J-lead, gull wing, exposed pad, and a wide variety of metric sizes as well as through-hole TO-252, DPak, SC-63, and radial lead configurations.
Sourcing LED Engin LED Lighting - Color: in-stock lines for quick ship, BOM matching for multi-line builds, and original-channel screening — not keyword stuffing.
Product List
Total Components: 60
| Product | Pricing | Datasheet | Color | Mounting Type | Size / Dimension | Current - Max | Current - Test | Lumens/Watt @ Current - Test | Luminous Flux @ Current/Temperature | Temperature - Test | Height - Seated (Max) | Package / Case | Supplier Device Package | Viewing Angle | Voltage - Forward (Vf) (Typ) | Wavelength | Stock & Quantity |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LZ4-00MC00-0000 LED Engin | Red, Green, Blue (RGB) | Surface Mount | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 1A Red, 1A Green, 1A Blue | 700mA Red, 700mA Green, 700mA Blue | 75 lm/W Red, 59 lm/W Green, 13 lm/W Blue | 115lm Red, 290lm Green, 31lm Blue | 25°C | 0.173" (4.40mm) | 2828 (7070 Metric) | SMD | 95° | 2.2V Red, 7V Green, 3.5V Blue | 624nm Red, 525nm Green, 457nm Blue | 1,429 | ||
LZ4-00MD00-0000 LED Engin | Red, Green, Blue, White - Cool (RGBW) | Surface Mount | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 1A Red, 1A Green, 1A Blue, 1A White | 700mA Red, 700mA Green, 700mA Blue, 700mA White | 75 lm/W Red, 68 lm/W Green, 13 lm/W Blue, 85 lm/W White | 115lm Red, 160lm Green, 30lm Blue, 190lm White | 25°C | 0.173" (4.40mm) | 2828 (7070 Metric) | SMD | 95° | 2.2V Red, 3.35V Green, 3.2V Blue, 3.2V White | 624nm Red, 525nm Green, 457nm Blue, 6658K White | 3,693 | ||
LZ4-00MD06-0000 LED Engin | Red, Green, Blue, White - Cool (RGBW) | Surface Mount | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 1A Red, 1A Green, 1A Blue, 1A White | 700mA Red, 700mA Green, 700mA Blue, 700mA White | 55 lm/W Red, 63 lm/W Green, 13 lm/W Blue, 85 lm/W White | 85lm Red, 148lm Green, 30lm Blue, 190lm White | 25°C | 0.173" (4.40mm) | 2828 (7070 Metric) | SMD | 95° | 2.2V Red, 3.35V Green, 3.2V Blue, 3.2V White | 624nm Red, 525nm Green, 457nm Blue, 6658K White | 4,179 | ||
LZC-03MA07-0000 LED Engin | Red, Green, Blue, Amber (RGBA) | Surface Mount | 0.354" L x 0.354" W (9.00mm x 9.00mm) | 1A Red, 1A Green, 1A Blue, 1A Amber | 700mA Red, 700mA Green, 700mA Blue, 700mA Amber | 49 lm/W Red, 43 lm/W Green, 12 lm/W Blue, 49 lm/W Amber | 240lm Red, 315lm Green, 89lm Blue, 240lm Amber | 25°C | 0.220" (5.60mm) | 3535 (9090 Metric) | SMD | 95° | 7V Red, 10.5V Green, 10.5V Blue, 7V Amber | 624nm Red, 525nm Green, 457nm Blue, 593nm Amber | 8,816 | ||
LZC-03MC00-0000 LED Engin | Red, Green, Blue (RGB) | Surface Mount | 0.354" L x 0.354" W (9.00mm x 9.00mm) | 1A Red, 1A Green, 1A Blue | 700mA Red, 700mA Green, 700mA Blue | 49 lm/W Red, 36 lm/W Green, 12 lm/W Blue | 320lm Red, 425lm Green, 120lm Blue | 25°C | 0.220" (5.60mm) | 3535 (9090 Metric) | SMD | 95° | 9.4V Red, 16.8V Green, 14V Blue | 624nm Red, 525nm Green, 457nm Blue | 3,546 | ||
LZC-03MD07-0W60 LED Engin | Red, Green, Blue, White - Cool (RGBW) | Surface Mount | 0.354" L x 0.354" W (9.00mm x 9.00mm) | 1A Red, 1A Green, 1A Blue, 1A White | 700mA Red, 700mA Green, 700mA Blue, 700mA White | 69 lm/W Red, 53 lm/W Green, 12 lm/W Blue, 71 lm/W White | 340lm Red, 390lm Green, 89lm Blue, 525lm White | 25°C | 0.220" (5.60mm) | 3535 (9090 Metric) | SMD | 95° | 7V Red, 10.5V Green, 10.5V Blue, 10.5V White | 624nm Red, 525nm Green, 457nm Blue, 6000K White | 8,280 | ||
LZC-03MD07-0W70 LED Engin | Red, Green, Blue, White - Cool (RGBW) | Surface Mount | 0.354" L x 0.354" W (9.00mm x 9.00mm) | 1A Red, 1A Green, 1A Blue, 1A White | 700mA Red, 700mA Green, 700mA Blue, 700mA White | 69 lm/W Red, 53 lm/W Green, 12 lm/W Blue, 71 lm/W White | 340lm Red, 390lm Green, 89lm Blue, 525lm White | 25°C | 0.220" (5.60mm) | 3535 (9090 Metric) | SMD | 95° | 7V Red, 10.5V Green, 10.5V Blue, 10.5V White | 624nm Red, 525nm Green, 457nm Blue, 7000K White | 2,762 | ||
LZ1-00A100-0000 LED Engin | Amber | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | 43 lm/W | 111lm (75lm ~ 146lm) | 25°C | 0.114" (2.90mm) | 1816 (4540 Metric) | SMD | 76° | 2.6V | 593nm (588nm ~ 598nm) | 5,972 | ||
LZ1-00B200-0000 LED Engin | Blue | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | 13 lm/W | 42lm (24lm ~ 60lm) | 25°C | 0.118" (3.00mm) | 1816 (4540 Metric) | SMD | 80° | 3.3V | 455nm (450nm ~ 460nm) | 2,575 | ||
LZ1-00DB00-0000 LED Engin | Blue | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | - | 1025mW (800mW ~ 1250mW) | 25°C | 0.118" (3.00mm) | 1816 (4540 Metric) | SMD | 80° | 3.6V | 460nm (457nm ~ 463nm) | 2,957 | ||
LZ1-00G100-0G23 LED Engin | Green | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | 57 lm/W | 215lm (145lm ~ 285lm) | 25°C | 0.114" (2.90mm) | 1816 (4540 Metric) | SMD | 80° | 3.75V | 525nm (520nm ~ 530nm) | 6,063 | ||
LZ1-00R200-0000 LED Engin | Red | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | - | 820mW (640mW ~ 1000mW) | 25°C | 0.114" (2.90mm) | 1816 (4540 Metric) | SMD | 90° | 2.5V | 663nm (655nm ~ 670nm) | 2,445 | ||
LZ1-00R300-0000 LED Engin | Red | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | - | 531mW (262mW ~ 800mW) | 25°C | 0.114" (2.90mm) | 1816 (4540 Metric) | SMD | 76° | 2.4V | 734nm (723nm ~ 745nm) | 2,037 | ||
LZ4-00R208-0000 LED Engin | Red | Surface Mount | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 1A | 700mA | - | 2500mW (2000mW ~ 3000mW) | 25°C | 0.154" (3.90mm) | 2828 (7070 Metric) | SMD | 95° | 10.5V | 663nm (655nm ~ 670nm) | 1,851 | ||
LZ4-04MDC9-0000 LED Engin | Red, Green, Blue, White - Cool (RGBW) | Surface Mount | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 1A Red, 1A Green, 1A Blue, 1A White | 700mA Red, 700mA Green, 700mA Blue, 700mA White | 35 lm/W Red, 53 lm/W Green, 11 lm/W Green, 82 lm/W | 62lm Red, 133lm Green, 24lm Blue, 183nm White | 25°C | 0.059" (1.50mm) | 2828 (7070 Metric) | SMD | 110° | 2.5V Red, 3.6V Green, 3.2V Blue, 3.2V White | 624nm Red, 525nm Green, 457nm Blue, 6500K White | 2,144 | ||
LZ4-04MDCA-0000 LED Engin | Red, Green, Blue, White - Cool (RGBW) | Surface Mount | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 1.5A Red, 1.5A Green, 1.5A Blue, 1.5A White | 700mA Red, 700mA Green, 700mA Blue, 700mA White | 35 lm/W Red, 53 lm/W Green, 11 lm/W Green, 82 lm/W | 62lm Red, 133lm Green, 24lm Blue, 183nm White | 25°C | 0.065" (1.65mm) | 2828 (7070 Metric) | SMD | 110° | 2.5V Red, 3.6V Green, 3.2V Blue, 3.2V White | 624nm Red, 525nm Green, 457nm Blue, 6500K White | 4,166 | ||
LZ1-00A102-0000 LED Engin | Amber | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | 43 lm/W | 111lm (75lm ~ 146lm) | 25°C | 0.102" (2.60mm) | 1816 (4540 Metric) | SMD | 100° | 2.6V | 593nm (588nm ~ 598nm) | 3,183 | ||
LZ1-00G102-0G23 LED Engin | Green | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.5A | 1A | 57 lm/W | 215lm (145lm ~ 285lm) | 25°C | 0.102" (2.60mm) | 1816 (4540 Metric) | SMD | 100° | 3.6V | 525nm (520nm ~ 530nm) | 2,857 | ||
LZ1-00G100-0000 LED Engin | Green | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | 57 lm/W | 215lm (145lm ~ 285lm) | 25°C | 0.114" (2.90mm) | 1816 (4540 Metric) | SMD | 80° | 3.75V | 528nm (520nm ~ 535nm) | 4,869 | ||
LZ1-00R100-0000 LED Engin | 1 $6.3000 | Red | Surface Mount | 0.173" L x 0.173" W (4.40mm x 4.40mm) | 1.2A | 1A | 67 lm/W | 173lm (117lm ~ 228lm) | 25°C | 0.114" (2.90mm) | 1816 (4540 Metric) | SMD | 76° | 2.6V | 624nm (618nm ~ 630nm) | 7,097 |
